Well Water Shock Chlorination Dosage Planner for Private Wells
Introduction: Why shock chlorination doses for private wells must be sized carefully
After a pump repair, flood, or positive bacteria test, the hard part of shock chlorination is not pouring the disinfectant; it is knowing how much the whole well system actually needs. A private well may hold a tall column of water in the casing, plus extra water in the pressure tank and house plumbing, and every gallon changes the treatment dose. This planner turns those measurements into a starting point so you can prepare the right amount of bleach or calcium hypochlorite before you mix anything.
The required dose depends on both the target chlorine level and the strength of the product on the shelf. Household bleach, concentrated bleach, and calcium hypochlorite all supply available chlorine at different rates, so the same target concentration does not translate into the same number of cups or pounds. Comparing the product strengths side by side helps you decide whether the liquid or dry option is easier to handle for your well.
Because well geometry is usually close to a cylinder, the math stays manageable, but the inputs still need to be measured carefully. Use the inside diameter of the casing, not the outside, and use a stabilized static water level rather than a level taken while the pump is cycling. The formulas below show how the planner converts diameter, depth, stored water, and contact time into a shock chlorination plan you can review before you act.
Plain-text formula: wellVolumeGal = pi * (diameterInches / 24)^2 * waterColumnFt * 7.48052; totalGal = wellVolumeGal + pressureTankGal + plumbingGal; requiredChlorineGrams = targetMgL * totalGal * 3.78541 / 1000; bleachLiters = requiredChlorineGrams / (bleachPercent / 100 * 1080); hypochloriteGrams = requiredChlorineGrams / (calciumPercent / 100).
Breaking down the well shock chlorination volume and dosage formulas
Plain formulas: wellVolumeGal = pi * (diameterInches / 24)^2 * waterColumnFt * 7.48052; requiredChlorineGrams = targetMgL * totalGal * 3.78541 / 1000; bleachLiters = requiredChlorineGrams / availableChlorineGramsPerLiter.
For well-water shock chlorination, the first calculation is the water volume inside the casing. If the static water level is hs feet below the top of the casing and the total depth is ht, then the height of the standing water column is hw = ht − hs. Let the inside diameter of the casing be d inches, so the radius in feet is d divided by 24. The volume in cubic feet is the area of that circle times the height, and 7.48052 converts cubic feet to U.S. gallons:
Formula: V_well = π × (d/24)^2 × h_w × 7.48052
That single expression produces the gallons-per-foot figures published in well disinfection guides: 0.65 gallons per foot for a 4-inch casing, 1.02 for a 5-inch, 1.47 for a 6-inch, and 2.61 for an 8-inch. Those match the rounded table values (0.7, 1.0, 1.5 and 2.6) in the University of Nevada Reno Extension shock chlorination fact sheet, which is a useful check that your measurements and the arithmetic agree.
After calculating the well volume, the next step is to add the water stored in the pressure tank and the stagnant water sitting in household plumbing and the water heater. These extra gallons keep the chlorine dose from being diluted below the target when treated water is moved through faucets, showers, and outdoor spigots:
Formula: V_total = V_well + V_tank + V_plumbing
Converting that total into liters by multiplying by 3.78541 lets us work with a target concentration in milligrams per litre. The mass of available chlorine required is the product of the treated litres and the target concentration, expressed here in grams:
Formula: m_Cl = (C_target × V_total × 3.78541) / 1000
Liquid bleach carries a smaller fraction of available chlorine than dry calcium hypochlorite, and the percentage on the label refers to weight, not volume. Assuming a solution density of 1.08 grams per millilitre, a 5.25 percent product supplies about 56.7 grams of available chlorine per litre and a 6 percent product about 64.8 grams per litre. The volume of bleach needed is the required chlorine mass divided by that per-litre availability:
Formula: V_bleach = m_Cl / (p / 100 × 1080)
Calcium hypochlorite granules, by contrast, are typically 65 to 70 percent available chlorine by weight, so the mass of granules you must dissolve is simply the required chlorine mass divided by that fraction:
Formula: m_hypo = m_Cl / (f / 100)
The calculator performs both conversions and presents results in litres, U.S. gallons, cups, grams, and ounces so that you can measure the dose using household equipment. Finally, contact time matters as much as dosage. The usual recommendation is to let the chlorinated water sit in the system for 12 to 24 hours so the disinfectant can reach the casing, the drop pipe, the pressure tank, and the stagnant plumbing lines. The planner uses your chosen contact time to frame the sequence of circulation, resting, and flushing that follows.
Casing size, water volume, and product dose compared
The table below compares four common casing sizes for a 100-foot standing water column at a 200 mg/L target, so you can see how quickly the dose grows with diameter. The casing volume alone is shown; a real job also carries the pressure tank, water heater, and plumbing.
| Casing inside diameter | Gallons per foot | Gallons in 100 ft column | Available chlorine needed (g) | Cups of 5.25% bleach | Cups of 8.25% bleach | Ounces of 70% granules |
|---|---|---|---|---|---|---|
| 4 inches | 0.65 | 65.3 | 49.4 | 3.7 | 2.3 | 2.5 |
| 5 inches | 1.02 | 102.0 | 77.2 | 5.8 | 3.7 | 3.9 |
| 6 inches | 1.47 | 146.9 | 111.2 | 8.3 | 5.3 | 5.6 |
| 8 inches | 2.61 | 261.1 | 197.7 | 14.7 | 9.4 | 10.0 |
How published guidance compares
| Source | Target concentration | Contact time | Notes |
|---|---|---|---|
| CDC, disinfecting wells after an emergency | Greater than 100 mg/L | Minimum 12 hours | Dosing tables by casing diameter and water depth; unscented household bleach only; recommends a well or pump contractor. |
| University of Nevada Reno Extension FS-06-69 | 250 mg/L | 12 hours | 7 cups of 5.25% bleach per 100 gallons of treated system volume; gallons-per-foot table by casing diameter. |
| Maine CDC Drinking Water Program | Dose table for 6-inch bedrock wells | 12 hours minimum, 24 hours recommended | Uses 6% bleach; two-thirds of the listed amount for 8.5% concentrated bleach; bypass treatment equipment first. |
Worked example: comparing bleach strengths for a private well
Take the planner defaults: a 6-inch casing, 180 feet of total depth, and a static water level 40 feet down. The standing water column is 140 feet, and at 1.47 gallons per foot the casing holds about 205.6 gallons. Adding a 40-gallon pressure tank drawdown and 60 gallons of household plumbing gives 305.6 gallons of treated volume, or 1,156.8 litres. At a 200 mg/L target that is 231.4 grams of available chlorine.
With 6 percent bleach at 64.8 grams of available chlorine per litre, that works out to 3.57 litres, which is 0.94 U.S. gallons or about 15.1 cups. Switch the strength selector to 8.25 percent concentrated bleach and the same job needs only 2.60 litres, about 0.69 gallons. Switch to calcium hypochlorite at 65 percent and you weigh out 356 grams, or 0.78 pounds, of granules instead. The chlorine mass never changes; only the packaging does.
A practical way to use the planner is to hold the well dimensions steady and compare how the dose changes when you switch bleach strength or change the target concentration. Deeper water columns and larger storage volumes push the chlorine requirement up, while a stronger bleach label pulls the liquid volume down. Calcium hypochlorite usually changes the amount you weigh out rather than the plumbing math, so it is a useful cross-check when one product is easier to obtain than another.
That comparison matters after a repair or contamination event, when you may know the well dimensions but not yet know which product you will buy. If the result looks awkward to carry or mix, adjust the strength selector and compare the output with a second scenario before you start. Recheck the diameter and static level if a small change in one field makes the dose jump far more than you expected; in a well treatment plan, an input error is usually easier to correct before mixing than after the chlorine is in the casing.
Planning the flush and fixture rotation for shock chlorination
In a well-water shock chlorination job, the flush plan matters as much as the dose, because the treated water must reach the casing, the pressure tank, and the indoor plumbing before you drain it away. Once the disinfectant has circulated through the system and the contact period is over, the question becomes how to move that chlorinated water out in a controlled way without overloading the septic system or dumping it where it can damage landscaping.
Fast discharge points usually help move chlorinated water through the system more quickly, while low-flow fixtures can take longer to purge. Rather than chasing a single exact runtime, use the planner to decide which faucets or hose bibbs you will open first, which ones you will use only briefly to confirm chlorine reaches the line, and where the discharge water can go without harming septic systems, lawns, or gravel driveways. If you know a fixture is slow or awkward, leave it out of the main purge until the chlorine odour is already established elsewhere.
The goal is to spread the disinfectant through the system first and then release it in a controlled way, not to run every tap at once and overwhelm the disposal area. A deliberate rotation through outdoor spigots, utility sinks, and indoor taps usually makes the purge easier to manage, especially when the well, the pressure tank, and the household plumbing all need to be cleared before normal use resumes.
Safety rules and monitoring residual chlorine after well shock chlorination
Never mix chlorine products with acids, ammonia, toilet-bowl cleaners, or descalers. Those combinations release chlorine gas. Mix and pour in the open air or a well-ventilated space, wear chemical-splash goggles and gloves, and keep children and pets clear of the wellhead and the buckets. Do not enter a well pit: the CDC warns that gases and vapours build up in well pits and create a hazardous environment. Do not drink, cook with, or bathe in the water until the system has been flushed and retested. Store enough drinking water for people and pets before you start, because the entire household supply is out of service for the whole contact period.
Use unscented plain bleach only, with a label suitable for disinfection, and check the pressure tank manufacturer's guidance before exposing a bladder tank to strong chlorine. Bypass any carbon filters, reverse osmosis membranes, or softener resin, and regenerate a softener before treatment; strong hypochlorite damages treatment media. Consult the local health department for contaminated wells, flood events, repeated positive bacteria tests, or questions about contact time and residual testing.
After the contact period and flush, test with a chlorine residual kit. Continue flushing until the chlorine odour and residual are gone or below local guidance before returning the well to regular service, then collect a bacteriological sample from a state-certified laboratory to verify that the disinfection succeeded. Maine CDC advises waiting for the chlorine to dissipate before sampling, because laboratories reject samples that still contain a trace of chlorine. If the residual falls too quickly, it can be a sign that the system needed more contact time or that the water carried more chlorine demand than expected.
Limitations and assumptions for this well shock chlorination planner
This well shock chlorination planner assumes a uniform well casing diameter and does not account for irregularities such as screen sections with different diameters or accumulation of sediment that displaces water. The static water level input should reflect the stabilized level after the well has rested; if you measure while the pump is running, you may underestimate the water column. Chlorine demand from iron, manganese, or organic matter can reduce the effective concentration, so heavily contaminated wells may require higher target levels or repeated treatments. Water pH matters too: Maine CDC notes that chlorine is far less effective as a biocide at pH 7.6 and above, which is common in deeper bedrock wells.
The calculator also presumes a bleach density of 1.08 grams per millilitre and treats the label percentage as available chlorine by weight. That convention reproduces the published extension tables closely, but industrial products, trade percentages quoted by volume, and aged bleach that has lost strength on the shelf can all deviate from it. Local regulations may dictate how chlorinated water is disposed of, and some jurisdictions require licensed professionals to perform disinfection after construction. This planner is an estimating aid, not a substitute for the procedure published by your state or provincial drinking water program.
Despite these caveats, quantifying the shock chlorination dose turns a stressful chore into a manageable maintenance task. Knowing exactly how much bleach to purchase, how long to circulate water, and when it is safe to resume normal use empowers private well owners to act quickly after contamination events. The detailed breakdown also helps homeowners communicate effectively with contractors or public health officials, showing how the treatment plan fits the well dimensions, the chosen product, and the desired contact time. With good measurements and deliberate execution, a shock chlorination can restore confidence in a well system and protect household health.
How to use this well shock chlorination dosage planner
- Enter Well casing inside diameter (inches) so the planner can estimate the casing cross-section. Measure the inside diameter, not the outside of the casing.
- Enter Total well depth (feet) so the calculator knows how much of the casing is filled with water.
- Enter Static water level measured from the top (feet), taken after the pump has been idle long enough for the level to stabilize, so the water column can be derived.
- Add the pressure tank drawdown and an estimate of the household plumbing and water heater volume, because those gallons dilute the dose if you leave them out.
- Choose a target concentration and a product strength, then run the calculation and compare the chlorine dose with a second scenario if you are unsure about bleach strength, contact time, or extra plumbing storage.
Frequently asked questions about shock chlorinating a private well
How much bleach does a 6-inch well need for shock chlorination?
A 6-inch casing holds about 1.47 gallons per foot of standing water, so a 100-foot water column is roughly 147 gallons. Treating that column alone to 200 mg/L takes about 8.3 cups of 5.25 percent unscented bleach, or about 5.3 cups of 8.25 percent concentrated bleach. Once you add a pressure tank and the household plumbing the treated volume often reaches 250 gallons, which raises the 5.25 percent dose to about 14 cups.
How long should the chlorinated water stay in the well?
CDC guidance says to leave the solution in the well and plumbing for a minimum of 12 hours. The Maine CDC Drinking Water Program uses the same 12-hour minimum and recommends 24 hours for a bedrock well. Plan on the household having no usable water for that whole period, arrange stored drinking water in advance, and label the fixtures so nobody draws chlorinated water for drinking, cooking, or bathing.
What target chlorine concentration should I plan for?
Published targets range from more than 100 mg/L in the CDC dosing tables to 250 mg/L in the University of Nevada Reno Extension fact sheet, and 200 mg/L is a common middle-ground choice. A higher target buys margin against chlorine demand from iron, manganese, and organic matter, but it also means more flushing afterwards and more risk to septic bacteria, pressure tank bladders, and water treatment media.
Can I use calcium hypochlorite granules instead of liquid bleach?
Yes. Calcium hypochlorite granules are usually 65 to 70 percent available chlorine, so the mass you need is the required chlorine mass divided by that fraction. About 2 ounces of 65 percent granules per 100 gallons produces roughly 100 mg/L. Always pre-dissolve the granules in a bucket of clean water in a well-ventilated place before pouring the solution into the casing, and never mix chlorine products with acids, ammonia, or other cleaners.
Where should the flush water go after shock chlorination?
Send the first and strongest flush to a gravel drive or another hard surface away from the septic field, surface water, and sensitive plants. Do not push large volumes of heavily chlorinated water into a septic tank, because chlorine kills the bacteria the tank depends on, and do not discharge it to a ditch, stream, pond, or storm drain. Keep flushing until a chlorine residual test kit reads clear, then wait before collecting a bacteria sample for a state-certified laboratory.
Sources checked for this planner. The gallons-per-foot geometry, the bleach and calcium hypochlorite conversions, and the contact-time guidance on this page were verified against: CDC, How to Disinfect Wells After an Emergency (dosing tables by casing diameter and water depth, target greater than 100 mg/L, minimum 12-hour contact time, well-pit and ventilation warnings); University of Nevada Reno Extension, Fact Sheet FS-06-69: Shock Chlorination, Estimating the Amount of Bleach Needed (gallons per foot of casing, 7 cups of 5.25% bleach per 100 gallons at 250 ppm for twelve hours); Maine CDC Drinking Water Program, Procedure for Shock Chlorination of Water Systems Using Bedrock Wells (12-hour minimum with 24 hours recommended, two-thirds dose for 8.5% concentrated bleach, pH effects, disposal cautions); and US EPA, Protect Your Home's Water (private well testing and maintenance context). The planner's own arithmetic reproduces the Nevada Extension table to within one part in a hundred: 100 gallons at 250 mg/L with 5.25% bleach computes to 7.05 cups against the published 7 cups.
Shock Sequence: run a whole well disinfection, start to finish
Shock chlorination is a procedure, not just a dose. Each run gives you a randomly generated well: read the casing diameter and standing water column on the cross-section, mix a dose that lands on 200 mg/L, pour it in, recirculate it back down the casing, purge every fixture until chlorine is smelled at the tap, hold the contact time, and then flush the spent water somewhere that will not kill a septic field or a creek.
- Keyboard: the well diagram is focusable. Use Up and Down to change the dose by a quarter cup, Left and Right to change it by a full cup or to move between fixtures and discharge points, and Space or Enter to perform the highlighted step.
- Pointer and touch: tap or drag the graduated jug to set the dose, tap a fixture or a discharge point to select it, and tap the glowing action bar at the bottom of the panel to perform the step.
- Buttons: Restart run generates a fresh well; Reset scoreboard clears the best score.
Focus the well diagram and set the bleach dose so the residual lands on 200 mg/L.
| Step | Action | Details |
|---|
